Scrap Bailing Machines
Shearing Box Machine
For work involving sheet blanks, plate, bars, or title-specific scrap, the Shearing Box Machine offers a process-specific solution. It passes a moving blade through material supported at the cutting zone, with guided blade movement and stable material support.
Order By Phone
Shipping Information Usually dispatched With In business days
Overview
Product Overview
Shearing Box Machine
Machine Purpose
For facilities needing cutting sheet, plate, sections, or scrap without conventional sawing, the Shearing Box Machine offers a process-specific workstation. Its arrangement supports sheet blanks, plate, bars, or title-specific scrap while keeping the important operating area accessible.
Industrial Applications
Likely users are found in fabrication shops, recycling yards, and metal processors. They may use it to organise the named operation, reduce repeated handling, and establish a consistent workstation for suitable jobs.
How It Works
Its cycle is based on the way it passes a moving blade through material supported at the cutting zone. The design therefore prioritises guided blade movement and stable material support; actual output still depends on the chosen model, tool, workpiece, and operating method.
Selection Considerations
When comparing versions of the Shearing Box Machine, buyers should review the work envelope, tooling, control method, loading, and service access. Numerical capacity, speed, accuracy, or power must be confirmed from the selected model’s documented specification.
Pathak is a Manufacturer, Supplier and Exporter offering this machine with application-based product guidance.
Specifications
Technical Specifications
| Specification | PBSM-630 | PBSM-800 | PBSM-1000 | PBSM-1250 |
|---|---|---|---|---|
| Maximum shear force | 630 ton | 800 ton | 1000 ton | 1250 ton |
| Cutting width | 1400 mm | 1600 mm | 1600 mm | 1800 mm |
| Feed inlet size | 2000x1400 mm | 2200x1600 mm | 2200x1600 mm | 2200x1800 mm |
| Maximum cutting range | 100x100 steel, 105 round steel | Square steel 120x120, round steel 140 | Square steel 130x130, round steel 160 | Square steel 180x180, round steel 200 |
| Main motor power | 4x45 KW | - | - | - |
Applications
Applications
Shearing Box Machine Application Image 1
Shearing Box Machine Application Image 2
Shearing Box Machine Application Image 3
Shearing Box Machine Application Image 4
FAQs
Frequently Asked Questions
Why is a Shearing Box Machine used in industrial work?
The Shearing Box Machine is intended for cutting sheet, plate, sections, or scrap without conventional sawing. It is arranged around sheet blanks, plate, bars, or title-specific scrap, giving operators a dedicated method for this specific stage of production, preparation, assembly, finishing, testing, or repair.
What happens during operation of a Shearing Box Machine?
The machine passes a moving blade through material supported at the cutting zone. Its guided blade movement and stable material support supports a controlled sequence, although the exact setup, tooling, feed, and operating parameters must follow the selected model and the job being processed.
What workpieces or materials can a Shearing Box Machine handle?
It is primarily associated with sheet blanks, plate, bars, or title-specific scrap. Suitability depends on the material, shape, size, required operation, tooling, and rated capacity, so the actual workpiece should be checked against the product specification before use.
Where is a Shearing Box Machine typically installed?
Typical users include fabrication shops, recycling yards, and metal processors. In these settings, the Shearing Box Machine may operate as a standalone workstation or as one stage within a broader manufacturing, fabrication, maintenance, or quality-control process.
Which factors matter when selecting a Shearing Box Machine?
Start with the real workpiece and required operation. Compare working range, compatible tooling, control method, production frequency, loading arrangement, available space, utilities, guarding, and service access. Confirm every numerical requirement from the selected model’s technical data rather than relying on the general machine name.
What maintenance checks are important for a Shearing Box Machine?
Keep the working area clean and inspect the tool, work supports, guards, fasteners, transmission elements, lubrication points, and relevant electrical, hydraulic, or pneumatic systems. Follow the maintenance schedule supplied for the machine, isolate all energy before servicing, and replace guards before returning it to operation.
What factors affect the price of a Shearing Box Machine?
Price depends on the required working range, construction, drive and control arrangement, tooling, automation, accessories, guarding, inspection requirements, freight, and installation support. A meaningful quotation therefore needs the intended application and workpiece details, not only the title Shearing Box Machine.
