Automobile Garage Machines
Reboring Cylindrical Machine
Built around enlarging and correcting existing holes, the Reboring Cylindrical Machine provides a dedicated working arrangement. Its rigid spindle guidance for internal machining suits machine shops, engine repair, and heavy maintenance.
Order By Phone
Shipping Information Usually dispatched With In business days
Overview
Product Overview
Reboring Cylindrical Machine
Machine Purpose
The Reboring Cylindrical Machine provides a dedicated method of enlarging and correcting existing holes. Rather than acting as unrelated general equipment, it brings the working elements together around castings, housings, cylinders, and machine parts.
How It Works
In operation, it positions a boring tool accurately within the supported component. The practical focus is rigid spindle guidance for internal machining. Correct workholding, tooling, supervision, and routine inspection remain important because results depend on the material and setup.
Industrial Applications
The machine is applicable to machine shops, engine repair, and heavy maintenance. It can support individual jobs, recurring batches, or a dedicated station between earlier preparation and later inspection.
Selection Considerations
Selection should follow the real workpiece, material, operation, production frequency, handling method, and available space. Exact performance data must come from the technical specification for the chosen Reboring Cylindrical Machine.
Pathak is a Manufacturer, Supplier and Exporter offering this machine with application-based product guidance.
Specifications
Technical Specifications
| Model | PCB 048 | PCB 055 | PCB 038(With Stand) | PCB 065 | |
|
Uses
|
Motor Cycle | Motor Cycle | Moped | Heavy Car, Medium Compressor Diesel Vehicle | |
| Light Car | Light & Medium Car | Mtor Cycle CC |
-
|
||
| Scooter | Scooter |
-
|
-
|
||
|
-
|
Three Wheeler Car |
-
|
-
|
||
|
-
|
Medium Duty Compressor |
-
|
-
|
||
| Boring Capacity | Range of Bore mm | 48.0mm (1.900) 76mm~(3.000'') |
53.5(2.100'') 90 (3.700'') |
38.1 mm (1.500'') 60mm (2.350'') |
66 mm (2.600'') 120 mm (5'') |
| Depth of bore mm | 200 mm (8'') | 245 mm (9.700'') | 150 mm (6.000'') | 300 mm (12'') | |
| Spindle Speed (50 Cycle) | High RMP | 420~ | 420~ | 460 | 225 RMP |
| Low RMP | 345~ | 345~ |
-
|
142 RMP | |
| Rate of Cut | High mm/min. | 42(1.65'')~ | 42(1.65'')~ |
-
|
43 mm/Min |
| Low mm/min. | 35(1.38'')~ | 35(1.38'')~ |
-
|
27 mm/Min | |
| Rate of Feed mm | 0.09~ | 0.09~ | 0.09~ | 0.09 | |
| Max depth of cut mm (at Low Speed) | 1(0.040'')~ | 1(0.040'')~ | 0.8 (0.030'') | 1.0mm(0.040'') | |
| Motor | Single Phase 1/3 HP | Single Phase 1/3 HP | Single Phase 1/3 HP | Single Phase 1HP / Three Phase 1HP |
|
| Single Phase 1/3 HP 200v220v | Single Phase 1/3 HP 200v220v | Three Phase 1/3 HP |
-
|
||
| Net Weight (Tool Box not included ) kg. Approx | 63.5 | 63.5 |
-
|
-
|
|
Videos
Product Videos
FAQs
Frequently Asked Questions
What does a Reboring Cylindrical Machine do?
The Reboring Cylindrical Machine is intended for enlarging and correcting existing holes. It is arranged around castings, housings, cylinders, and machine parts, giving operators a dedicated method for this specific stage of production, preparation, assembly, finishing, testing, or repair.
How does the Reboring Cylindrical Machine complete its working cycle?
The machine positions a boring tool accurately within the supported component. Its rigid spindle guidance for internal machining supports a controlled sequence, although the exact setup, tooling, feed, and operating parameters must follow the selected model and the job being processed.
What material should be prepared for a Reboring Cylindrical Machine?
It is primarily associated with castings, housings, cylinders, and machine parts. Suitability depends on the material, shape, size, required operation, tooling, and rated capacity, so the actual workpiece should be checked against the product specification before use.
Which industries commonly use a Reboring Cylindrical Machine?
Typical users include machine shops, engine repair, and heavy maintenance. In these settings, the Reboring Cylindrical Machine may operate as a standalone workstation or as one stage within a broader manufacturing, fabrication, maintenance, or quality-control process.
What should be checked before buying a Reboring Cylindrical Machine?
Start with the real workpiece and required operation. Compare working range, compatible tooling, control method, production frequency, loading arrangement, available space, utilities, guarding, and service access. Confirm every numerical requirement from the selected model’s technical data rather than relying on the general machine name.
Which parts of a Reboring Cylindrical Machine need regular inspection?
Keep the working area clean and inspect the tool, work supports, guards, fasteners, transmission elements, lubrication points, and relevant electrical, hydraulic, or pneumatic systems. Follow the maintenance schedule supplied for the machine, isolate all energy before servicing, and replace guards before returning it to operation.
Which options influence the quotation for a Reboring Cylindrical Machine?
Price depends on the required working range, construction, drive and control arrangement, tooling, automation, accessories, guarding, inspection requirements, freight, and installation support. A meaningful quotation therefore needs the intended application and workpiece details, not only the title Reboring Cylindrical Machine.
