Grinding Machines
Manual Vertical Surface Grinder
The Manual Vertical Surface Grinder handles plates, dies, tooling, and machine parts through a layout intended for producing flat, smooth component surfaces. Its stable table movement and controlled wheel engagement suits tool rooms, die shops, repair facilities, and precision plants. Manual control keeps setup and movement under direct operator supervision. The vertical arrangement affects loading, support, and access to the…
Order By Phone
Shipping Information Usually dispatched With In business days
Overview
Product Overview
Manual Vertical Surface Grinder
Machine Purpose
Used for producing flat, smooth component surfaces, the Manual Vertical Surface Grinder addresses a distinct stage of industrial work. It accommodates plates, dies, tooling, and machine parts and keeps setup, tool engagement, and job handling centred on that task.
Industrial Applications
The machine is applicable to tool rooms, die shops, repair facilities, and precision plants. It can support individual jobs, recurring batches, or a dedicated station between earlier preparation and later inspection.
How It Works
A typical cycle begins with locating the job correctly, after which the machine passes supported work beneath a rotating abrasive wheel. Its stable table movement and controlled wheel engagement supports repeat work without replacing the need for trained operation. Manual control keeps setup and movement under direct operator supervision. The vertical arrangement affects loading, support, and access to the work.
Selection Considerations
Machines within grinding machines can differ in arrangement and capability. The required Manual Vertical Surface Grinder should therefore be matched to actual samples or process details, with tooling, controls, guarding, and utilities verified before ordering.
Pathak is a Manufacturer, Supplier and Exporter offering this machine with application-based product guidance.
Specifications
Technical Specifications
| Models | PPSC-20 | PPSC-24 | PPSC-30 |
| Working Surface of Table | 525X205 MM | 625X200 MM | 625x300 MM |
| Grinding Capacity | 500X200 MM | 600X200 MM | 600X300 MM |
| Longitudinal Traverse | 525 MM | 610 MM | 630 MM |
| Cross Traverse | 215 MM | 215 MM | 320 MM |
| Vertical Traverse | 250 MM | 250 MM | 330 MM |
| Grinding Wheel Dia and Width | 200X12 MM | 200X12 MM | 200X12 MM |
| Spindle Speed | 2800 RPM | 2800 RPM | 2800 RPM |
| Cross Feed Graduation | .05 MM | .05 MM | .05 MM |
| Vertical Feed Graduation | .02 MM | .02 MM | .02 MM |
| Floor Space Requires | 1150X900 MM | 1250X1200 MM | 1850X1350 MM |
| Weight Gross | 1250X kgs. Approx | 1350 kgs. Approx | 1750 kgs. Approx |
|
ELECTRICALS
|
-
|
-
|
-
|
| Electrical Motors For Grinding Wheel | 1.0 H.P 2800 | 1.0 H.P 2800 |
-
|
| Elecrtrical Motor For Auto Feed Models Only |
-
|
1.0 H.P 1440 |
-
|
FAQs
Frequently Asked Questions
What is a Manual Vertical Surface Grinder used for?
The Manual Vertical Surface Grinder is intended for producing flat, smooth component surfaces. It is arranged around plates, dies, tooling, and machine parts, giving operators a dedicated method for this specific stage of production, preparation, assembly, finishing, testing, or repair.
What is the working principle of a Manual Vertical Surface Grinder?
The machine passes supported work beneath a rotating abrasive wheel. Its stable table movement and controlled wheel engagement supports a controlled sequence, although the exact setup, tooling, feed, and operating parameters must follow the selected model and the job being processed.
Which components are normally processed on a Manual Vertical Surface Grinder?
It is primarily associated with plates, dies, tooling, and machine parts. Suitability depends on the material, shape, size, required operation, tooling, and rated capacity, so the actual workpiece should be checked against the product specification before use.
What type of workshop needs a Manual Vertical Surface Grinder?
Typical users include tool rooms, die shops, repair facilities, and precision plants. In these settings, the Manual Vertical Surface Grinder may operate as a standalone workstation or as one stage within a broader manufacturing, fabrication, maintenance, or quality-control process.
How do I choose the right Manual Vertical Surface Grinder?
Start with the real workpiece and required operation. Compare working range, compatible tooling, control method, production frequency, loading arrangement, available space, utilities, guarding, and service access. Confirm every numerical requirement from the selected model’s technical data rather than relying on the general machine name.
How should a Manual Vertical Surface Grinder be maintained for reliable operation?
Keep the working area clean and inspect the tool, work supports, guards, fasteners, transmission elements, lubrication points, and relevant electrical, hydraulic, or pneumatic systems. Follow the maintenance schedule supplied for the machine, isolate all energy before servicing, and replace guards before returning it to operation.
How is a Manual Vertical Surface Grinder price determined?
Price depends on the required working range, construction, drive and control arrangement, tooling, automation, accessories, guarding, inspection requirements, freight, and installation support. A meaningful quotation therefore needs the intended application and workpiece details, not only the title Manual Vertical Surface Grinder.
When is manual operation useful on a Manual Vertical Surface Grinder?
Manual control keeps setup and movement under direct operator supervision. The vertical arrangement affects loading, support, and access to the work. The practical benefit depends on how that arrangement matches the workpiece, cycle frequency, operator involvement, and surrounding production method.
