Hydraulic Press Brake Machine PHPB 1030
Sheet Metal Machines

Hydraulic Press Brake Machine PHPB 1030

The Hydraulic Press Brake Machine PHPB 1030 handles sheet blanks, panels, brackets, and profiles through a layout intended for forming straight bends in sheet and plate. The operating method supports enclosure production, ducting, and fabrication shops and centres on guided ram motion with adaptable tooling. Hydraulic actuation provides progressive force and controlled movement.

Enquire Now Technical Specifications

Order By Phone

Shipping Information Usually dispatched With In business days

+91-91240-09247 +91-88959-29247
Overview

Product Overview

Hydraulic Press Brake Machine PHPB 1030

Machine Purpose

For facilities needing forming straight bends in sheet and plate, the Hydraulic Press Brake Machine PHPB 1030 offers a process-specific workstation. Its arrangement supports sheet blanks, panels, brackets, and profiles while keeping the important operating area accessible.

Industrial Applications

Likely users are found in enclosure production, ducting, and fabrication shops. They may use it to organise the named operation, reduce repeated handling, and establish a consistent workstation for suitable jobs.

How It Works

In operation, it drives a punch into a matched die along the bend line. The practical focus is guided ram motion with adaptable tooling. Correct workholding, tooling, supervision, and routine inspection remain important because results depend on the material and setup. Hydraulic actuation provides progressive force and controlled movement.

Selection Considerations

Selection should follow the real workpiece, material, operation, production frequency, handling method, and available space. Exact performance data must come from the technical specification for the chosen Hydraulic Press Brake Machine PHPB 1030.

Pathak is a Manufacturer, Supplier and Exporter offering this machine with application-based product guidance.

Specifications

Technical Specifications

Model Tonage Bending Cap. M.M. (M.S) Table Width Clear Distance Ram Stroke Open Height Depth Power H.P. Speed App. Pr. Ret. Packing Dimension M.M. (LxWxH)
PHPB-212 20 1270 x 2 125 900 100 250 200 3 35-9-60 1400 x 1050 x 1900
PHPB-320 30 2030 x 2 125 1500 100 250 200 3 30-9-53 2200 x 1050 x 1900
PHPB-425 40 2540 x 2 150 2000 100 250 200 5 35-9-55 2200 x 1050 x 1900
PHPB-530 50 3125 x 2 175 2500 125 250 200 5 30-7-55 3300 x 1050 x 1900
PHPB-612 60 1270 x 4 175 900 125 330 200 5 25-6-50 1400 x 1200 x 2000
PHPB-620 60 2030 x 4 175 1550 125 330 200 5 26-6-50 2200 x 1200 x 2000
PHPB-825 80 2540 x 4 200 2000 150 330 250 7.5 37-6-41 2700 x 1500 x 2200
PHPB-1025 100 2540 x 6 200 2000 150 330 250 7.5 40-5-40 2700 x 1600 x 2300
PHPB-1030 100 3125 x 4 200 2500 150 330 250 7.5 40-5-40 3300 x 1600 x 2300
PHPB-1060 100 6000 x 2 200 5000 150 330 300 7.5 40-6-40 6200 x 1600 x 2300
PHPB-1225 120 2540 x 6 125 2000 150 330 300 10 41-6-41 2700 x 1700 x 2500
PHPB-1625 160 2540 x 8 125 2000 200 375 300 15 40-6-40 2700 x 1800 x 2500
PHPB-1630 160 3125 x 6 125 2500 200 375 300 15 40-6-40 3300 x 1800 x 2500
PHPB-2025 200 2540 x 10 250 2000 200 375 300 20 37-5-37 2700 x 2000 x 2600
PHPB-2030 200 3125 x 8 250 2500 200 375 300 20 37-5-37 3300 x 2000 x 2600
PHPB-2040 200 4000 x 6 250 3000 200 375 300 20 37-5-37 4200 x 2000 x 2600
PHPB-2060 200 6000 x 4 250 5000 200 375 300 20 37-5-37 6200 x 2000 x 2600
PHPB-2530 250 3125 x 10 250 2500 200 375 300 25 40-5-40 3300 x 2100 x 2700
PHPB-2540 250 4000 x 8 250 3000 200 375 300 25 40-5-40 4200 x 2100 x 2700
PHPB-2550 250 5000 x 6 250 4000 200 375 300 25 40-5-40 5200 x 2100 x 2700
PHPB-3025 300 2540 x 16 275 2000 200 425 300 30 36-5-36 2700 x 2150 x 2900
PHPB-3040 300 4000 x 10 275 3000 200 425 300 30 36-5-36 4200 x 2150 x 2900
PHPB-3060 300 6000 x 6 275 5000 250 425 300 30 36-5-36 6200 x 2150 x 2900
PHPB-4025 400 2540 x 20 300 2000 250 425 350 40 34-5-34 2700 x 2200 x 3000
PHPB-4030 400 3125 x 16 300 2500 250 450 350 40 34-5-34 3300 x 2200 x 3000
PHPB-5030 500 3125 x 20 350 2500 250 450 400 50 28-5-28 3300 x 2300 x 3200
PHPB-5040 500 4000 x 16 350 3000 250 450 400 50 28-5-28 4200 x 2300 x 3200
PHPB-5060 500 6000 x 10 350 5000 250 450 400 50 28-5-28 6200 x 2300 x 3200
FAQs

Frequently Asked Questions

Which operation is the Hydraulic Press Brake Machine PHPB 1030 designed to perform?
The Hydraulic Press Brake Machine PHPB 1030 is intended for forming straight bends in sheet and plate. It is arranged around sheet blanks, panels, brackets, and profiles, giving operators a dedicated method for this specific stage of production, preparation, assembly, finishing, testing, or repair.
How does a Hydraulic Press Brake Machine PHPB 1030 work?
The machine drives a punch into a matched die along the bend line. Its guided ram motion with adaptable tooling supports a controlled sequence, although the exact setup, tooling, feed, and operating parameters must follow the selected model and the job being processed.
What type of work is suitable for a Hydraulic Press Brake Machine PHPB 1030?
It is primarily associated with sheet blanks, panels, brackets, and profiles. Suitability depends on the material, shape, size, required operation, tooling, and rated capacity, so the actual workpiece should be checked against the product specification before use.
What are the common applications of a Hydraulic Press Brake Machine PHPB 1030?
Typical users include enclosure production, ducting, and fabrication shops. In these settings, the Hydraulic Press Brake Machine PHPB 1030 may operate as a standalone workstation or as one stage within a broader manufacturing, fabrication, maintenance, or quality-control process.
How can a buyer compare different Hydraulic Press Brake Machine PHPB 1030 models?
Start with the real workpiece and required operation. Compare working range, compatible tooling, control method, production frequency, loading arrangement, available space, utilities, guarding, and service access. Confirm every numerical requirement from the selected model’s technical data rather than relying on the general machine name.
What routine maintenance does a Hydraulic Press Brake Machine PHPB 1030 require?
Keep the working area clean and inspect the tool, work supports, guards, fasteners, transmission elements, lubrication points, and relevant electrical, hydraulic, or pneumatic systems. Follow the maintenance schedule supplied for the machine, isolate all energy before servicing, and replace guards before returning it to operation.
Why can the cost of a Hydraulic Press Brake Machine PHPB 1030 vary between models?
Price depends on the required working range, construction, drive and control arrangement, tooling, automation, accessories, guarding, inspection requirements, freight, and installation support. A meaningful quotation therefore needs the intended application and workpiece details, not only the title Hydraulic Press Brake Machine PHPB 1030.
How does hydraulic actuation affect the Hydraulic Press Brake Machine PHPB 1030?
Hydraulic actuation provides progressive force and controlled movement. The practical benefit depends on how that arrangement matches the workpiece, cycle frequency, operator involvement, and surrounding production method.
