Cutting Machines
Horizontal Double Column Bandsaw Machine Model - 250 S.A.
The Horizontal Double Column Bandsaw Machine Model - 250 S.A. handles bars, tubes, profiles, timber, or title-specific stock through a layout intended for cutting stock with a continuous band blade. It guides a tensioned loop blade through supported material, with continuous cutting with stable blade guidance. The horizontal layout supports work along a level machine axis.
Order By Phone
Shipping Information Usually dispatched With In business days
Overview
Product Overview
Horizontal Double Column Bandsaw Machine Model - 250 S.A.
Machine Purpose
The Horizontal Double Column Bandsaw Machine Model - 250 S.A. is a purpose-built unit for cutting stock with a continuous band blade. Its layout is organised around bars, tubes, profiles, timber, or title-specific stock, making it relevant when this operation must be completed in a controlled sequence.
How It Works
In operation, it guides a tensioned loop blade through supported material. The practical focus is continuous cutting with stable blade guidance. Correct workholding, tooling, supervision, and routine inspection remain important because results depend on the material and setup. The horizontal layout supports work along a level machine axis.
Industrial Applications
Natural settings include material stores, fabrication shops, sawmills, and workshops. There the machine may serve production, repair, preparation, assembly, finishing, or testing according to its title and the surrounding workflow.
Selection Considerations
Selection should follow the real workpiece, material, operation, production frequency, handling method, and available space. Exact performance data must come from the technical specification for the chosen Horizontal Double Column Bandsaw Machine Model - 250 S.A..
Pathak is a Manufacturer, Supplier and Exporter offering this machine with application-based product guidance.
Specifications
Technical Specifications
| Model | 250 S.A. | 250 H.L.C. |
| Cutting Capacity Round Bar(mm) | 250 | 250 |
| Square(mm) | 220x220 | 220x220 |
| Blade Size(mm) | 27x0.9x3200 | 27x0.9x3200 |
| Motor power | 0.85 H.P./960 RPM | 0.85 H.P./960 RPM |
| Coolant Pump Power | 0.15 H.P./2800 RPM | 0.15 H.P./2800 RPM |
| Hydraulic Drive Motor | 0.25 H.P./1500 RPM | 0.25 H.P./1500 RPM |
| Cutting Speed Control | Power Hydraulic | Power Hydraulic |
| Blade Speed Min/Mtr | 32/44/56 | 32/44/56 |
| Net Weight | 352 kg | 385 kg |
| Overall Dimension | 1500x825x1600(LxWxH) | 1500x825x1600(LxWxH) |
Videos
Product Videos
FAQs
Frequently Asked Questions
Why is a Horizontal Double Column Bandsaw Machine Model - 250 S.A. used in industrial work?
The Horizontal Double Column Bandsaw Machine Model - 250 S.A. is intended for cutting stock with a continuous band blade. It is arranged around bars, tubes, profiles, timber, or title-specific stock, giving operators a dedicated method for this specific stage of production, preparation, assembly, finishing, testing, or repair.
What happens during operation of a Horizontal Double Column Bandsaw Machine Model - 250 S.A.?
The machine guides a tensioned loop blade through supported material. Its continuous cutting with stable blade guidance supports a controlled sequence, although the exact setup, tooling, feed, and operating parameters must follow the selected model and the job being processed.
What workpieces or materials can a Horizontal Double Column Bandsaw Machine Model - 250 S.A. handle?
It is primarily associated with bars, tubes, profiles, timber, or title-specific stock. Suitability depends on the material, shape, size, required operation, tooling, and rated capacity, so the actual workpiece should be checked against the product specification before use.
Where is a Horizontal Double Column Bandsaw Machine Model - 250 S.A. typically installed?
Typical users include material stores, fabrication shops, sawmills, and workshops. In these settings, the Horizontal Double Column Bandsaw Machine Model - 250 S.A. may operate as a standalone workstation or as one stage within a broader manufacturing, fabrication, maintenance, or quality-control process.
Which factors matter when selecting a Horizontal Double Column Bandsaw Machine Model - 250 S.A.?
Start with the real workpiece and required operation. Compare working range, compatible tooling, control method, production frequency, loading arrangement, available space, utilities, guarding, and service access. Confirm every numerical requirement from the selected model’s technical data rather than relying on the general machine name.
What maintenance checks are important for a Horizontal Double Column Bandsaw Machine Model - 250 S.A.?
Keep the working area clean and inspect the tool, work supports, guards, fasteners, transmission elements, lubrication points, and relevant electrical, hydraulic, or pneumatic systems. Follow the maintenance schedule supplied for the machine, isolate all energy before servicing, and replace guards before returning it to operation.
What factors affect the price of a Horizontal Double Column Bandsaw Machine Model - 250 S.A.?
Price depends on the required working range, construction, drive and control arrangement, tooling, automation, accessories, guarding, inspection requirements, freight, and installation support. A meaningful quotation therefore needs the intended application and workpiece details, not only the title Horizontal Double Column Bandsaw Machine Model - 250 S.A..
How does horizontal arrangement affect the Horizontal Double Column Bandsaw Machine Model - 250 S.A.?
The horizontal layout supports work along a level machine axis. The practical benefit depends on how that arrangement matches the workpiece, cycle frequency, operator involvement, and surrounding production method.
